Model No. |
BSL80Z-F14L |
BSL100Z-F14L |
BSL120Z-F14L |
BSL150Z-F14L |
BSL180Z-F14L | |
|
Nominal Wattage |
80W |
100W |
120W |
150W |
180W | |
|
Input Voltage |
AC100-305V 50/60Hz or DC12/24V (with controller) |
|||||
|
Power Factor (P.F) |
>0.95 |
>0.95 |
>0.95 |
>0.95 |
>0.95 |
|
|
T.H.D |
< 20% |
< 20% |
< 20% |
< 20% |
< 20% |
|
|
Luminaire Efficacy |
>120lm/W(3030 LEDs) / >150lm/W(5050LEDs) |
|||||
|
C.R.I |
75±5 |
75±5 |
75±5 |
75±5 |
75±5 |
|
|
C.C.T |
3000K / 4000K / 5000K / 5700K / 6500K |
|||||
|
Rating |
IP66,IK10,CLASSⅡ |
IP66,IK10,CLASSⅡ |
IP66,IK10,CLASSⅡ |
IP66,IK10,CLASSⅡ |
IP66,IK10 ,CLASSⅡ |
|
|
Heat Radiator |
Anodized Aluminum |
Anodized Aluminum |
Anodized Aluminum |
Anodized Aluminum |
Anodized Aluminum |
|
|
LED Lens |
PC (UV Resistance) |
PC (UV Resistance) |
PC (UV Resistance) |
PC (UV Resistance) |
PC (UV Resistance) |
|
|
LED Brand |
Lumileds |
Lumileds |
Lumileds |
Lumileds |
Lumileds |
|
|
Pole Mounting Diameter |
Suitable for ∮40-60mm Pole | |||||
|
Warranty |
5 Years |
5 Years |
5 Years |
5 Years |
5 Years |
|
|
Thermal Conductivity of PCB board ﹥2.0 |
||||||
