Model No. |
BSL20Z-F14B |
BSL30Z-F14B |
BSL40Z-F14B |
BSL50Z-F14B |
BSL60Z-F14B |
BSL80Z-F14B |
BSL100Z-F14B |
BSL120Z-F14B |
BSL150Z-F14B |
BSL200Z-F14B |
|
Nominal Wattage |
20W |
30W | 40W | 50W | 60W | 80W | 100W | 120W |
150W |
200W |
|
Input Voltage |
AC100V～305V 50/60Hz or DC12/24V (with controller) |
|||||||||
|
Power Factor (P.F) |
>0.95 |
>0.95 |
>0.95 |
>0.95 |
>0.95 |
>0.95 |
>0.95 |
>0.95 |
>0.95 |
>0.95 |
|
Luminaire Efficacy |
>120lm/W(3030 LEDs) / >150lm/W(5050LEDs) |
|||||||||
|
C.R.I |
75±5 |
75±5 |
75±5 |
75±5 |
75±5 |
75±5 |
75±5 |
75±5 |
75±5 |
75±5 |
|
C.C.T |
3000K / 4000K / 5000K / 5700K / 6500K |
|||||||||
|
Rating |
IP66,IK10 |
IP66,IK10 |
IP66,IK10 |
IP66,IK10 |
IP66,IK10 |
IP66,IK10 |
IP66,IK10 |
IP66,IK10 |
IP66,IK10 |
IP66,IK10 |
|
LED Chips Info |
Lumileds |
Lumileds |
Lumileds |
Lumileds |
Lumileds |
Lumileds |
Lumileds |
Lumileds |
Lumileds |
Lumileds |
